KBD30
Au Viet Industrial Joint Stock Company – a genuine distributor of Baoli forklifts – a brand of KION group – Federal Republic of Germany. With the motto of bringing customers the best value, we have researched and selected famous brands from countries with the most advanced production science. Baoli forklift products with modern technological lines of KION Group – Germany have been confirmed in the world market, including demanding markets such as Europe and North America. Components of famous brands such as:
– Weichai engine – China
– Isuzu engine – Japan
– Mitsubishi engine – Japan
– KION hydraulics – Germany
– KION gearbox – Germany
*For each engine and hydraulic specifications, please refer to the catalogue for details or contact us directly.
No. | Description | Unit | Specification |
1 | Model | KBD30 | |
2 | Load Capacity | Q (Kg) | 3000 |
3 | Service weight | kg | 4260 |
4 | Tyres (SE - Super elastic; PN - Pneumatic) | PN | |
4.1 | Front tyres size | 28x9-15-14PR | |
4.2 | Rear tyres size | 6.50-10-10PR | |
5 | Mast lift, forward/backward | α/β (grad) | 6ᴼ/12ᴼ |
6 | Overall Length | L1 (mm) | 3780 |
7 | Overall Width | b1(mm) | 1225 |
8 | Drive Speed laden/unladen | km/h | 20/20.5 |
9 | Lifting Speed laden/unladen | mm/s | 480/540 |
10 | Engine Manufacturer/Engine Type | Weichai WP3.2 | |
11 | Emission Standard | China Stage III | |
12 | Engine Power | kW/ v/min | 36.8/2500 |
13 | Cylinder Number/Displacement | liter | 4/3170 |
14 | Transmission | Automatic |
